ESDA14V2LY
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 12V 21V SOT23-3
PDF
/
Buying Options
Total Price: USD $0.32
Unit Price: USD $0.3168
≥1 USD $0.3168
≥10 USD $0.24552
≥100 USD $0.147312
≥500 USD $0.136435
≥1000 USD $0.09277
Inventory: 32201
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Number of Pins 3
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q101, ESDAY, TRANSIL?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Zener
Applications Automotive
HTS Code 8541.10.00.50
Capacitance 90pF
Depth 1.3mm
Base Part Number ESDA14
Operating Supply Voltage 1.25V
Working Voltage 12V
Leakage Current 5μA
Element Configuration Dual
Power Line Protection No
Voltage - Breakdown (Min) 14.2V
Current - Peak Pulse (10/1000μs) 14A 8/20μs
Clamping Voltage 21V
Peak Pulse Current 14A
Reverse Standoff Voltage 12V
Peak Pulse Power 300W
Direction Bidirectional
Unidirectional Channels 2
Dimensions
Length 2.9mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
