BZW50-68B
RoHS
RoHS compliant
RoHS compliantPackage R6, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 68VWM 157VC R6
PDF
/
Buying Options
Total Price: USD $2.62
Unit Price: USD $2.6224
≥1 USD $2.6224
≥10 USD $2.17624
Inventory: 392
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case R6, Axial
Number of Pins 2
Weight 2.047998g
Diode Element Material SILICON
Technical
Packaging Tape & Box (TB)
Series BZW50, TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Axial
ECCN Code EAR99
Type Zener
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Applications General Purpose
Additional Feature UL RECOGNIZED
Capacitance 3nF
Subcategory Transient Suppressors
Power Rating 5kW
Voltage - Rated DC 68V
Technology AVALANCHE
Terminal Form WIRE
Base Part Number BZW50
Pin Count 2
Operating Supply Voltage 68V
Number of Elements 1
Polarity Bidirectional
Number of Channels 1
Leakage Current 5μA
Element Configuration Single
Power Dissipation 6.5W
Case Connection ISOLATED
Power Line Protection No
Power - Peak Pulse 5000W 5kW
Current - Peak Pulse (10/1000μs) 382A 8/20μs
Max Reverse Leakage Current 5μA
Clamping Voltage 157V
Peak Pulse Current 382A
Reverse Standoff Voltage 68V
Max Surge Current 382A
Peak Pulse Power 5kW
Test Current 1mA
Breakdown Voltage 75.6V
Capacitance @ Frequency 1500pF @ 1MHz
Reverse Breakdown Voltage 75.6V
Non-rep Peak Rev Power Dis-Max 5000W
Max Breakdown Voltage 75.6V
Dimensions
Diameter 9.1mm
Length 9.1mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
