BZW50-33RL
RoHS
RoHS compliant
RoHS compliantPackage R6, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 33VWM 76VC R6
PDF
/
Buying Options
Total Price: USD $2.38
Unit Price: USD $2.3848
≥1 USD $2.3848
≥10 USD $1.98088
≥100 USD $1.576872
≥500 USD $1.334238
Inventory: 2028
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case R6, Axial
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Series BZW50, TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Applications General Purpose
Additional Feature UL RECOGNIZED
Capacitance 5.75nF
Subcategory Transient Suppressors
Power Rating 5kW
Voltage - Rated DC 33V
Max Power Dissipation 5kW
Technology AVALANCHE
Terminal Form WIRE
Base Part Number BZW50
Pin Count 2
Operating Supply Voltage 33V
Number of Elements 1
Polarity Unidirectional
Leakage Current 5μA
Element Configuration Single
Power Dissipation 5kW
Case Connection ISOLATED
Power Line Protection No
Power - Peak Pulse 5000W 5kW
Current - Peak Pulse (10/1000μs) 789A 8/20μs
Max Reverse Leakage Current 5μA
Clamping Voltage 76V
Peak Pulse Current 789A
Reverse Standoff Voltage 33V
Max Surge Current 1mA
Peak Pulse Power 5kW
Test Current 1mA
Breakdown Voltage 36.6V
Number of Unidirectional Channels 1
Non-rep Peak Rev Power Dis-Max 5000W
Reverse Breakdown Voltage 36.6V
Capacitance @ Frequency 5750pF @ 1MHz
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 9.1mm
Diameter 9.1mm
