BZW50-22
RoHS
RoHS compliant
RoHS compliantPackage R6, Axial
Category Circuit Protection / TVS - Diodes
Description
STMICROELECTRONICS BZW50-22TVS Diode, TVS, Transil BZW50 Series, Unidirectional, 22 V, 51 V, R6, 2 Pins
PDF
/
Buying Options
Total Price: USD $2.38
Unit Price: USD $2.3848
≥1 USD $2.3848
≥10 USD $1.98088
Inventory: 526
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 9.1mm
Length 9.1mm
Height 9.1mm
Diameter 9.1 mm
Technical
Number of Unidirectional Channels 1
Max Breakdown Voltage 24.4V
Non-rep Peak Rev Power Dis-Max 5000W
Reverse Breakdown Voltage 24.4V
Capacitance @ Frequency 8500pF @ 1MHz
Breakdown Voltage 24.4V
Test Current 1mA
Peak Pulse Power 5kW
Max Surge Current 127A
Reverse Standoff Voltage 22V
Peak Pulse Current 1.177kA
Clamping Voltage 51V
Max Reverse Leakage Current 5μA
Current - Peak Pulse (10/1000μs) 1177A 1.177kA 8/20μs
Power - Peak Pulse 5000W 5kW
Power Line Protection No
Case Connection ISOLATED
Power Dissipation 6.5W
Element Configuration Single
Leakage Current 5μA
Polarity Unidirectional
Number of Elements 1
Operating Supply Voltage 22V
Pin Count 2
Base Part Number BZW50
Terminal Form WIRE
Technology AVALANCHE
Voltage - Rated DC 22V
Power Rating 5kW
Subcategory Transient Suppressors
Capacitance 8.5nF
Additional Feature UL RECOGNIZED
Applications General Purpose
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series BZW50, TRANSIL?
Packaging Tape & Box (TB)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case R6, Axial
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 11 Weeks
