BZW50-10
RoHS
RoHS compliant
RoHS compliantPackage R6, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 10VWM 23.4VC R6
PDF
/
Inventory: 8892
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Number of Unidirectional Channels 1
Non-rep Peak Rev Power Dis-Max 5000W
Reverse Breakdown Voltage 11.1V
Capacitance @ Frequency 24000pF @ 1MHz
Breakdown Voltage 11.1V
Test Current 1mA
Peak Pulse Power 5kW
Max Surge Current 266A
Reverse Standoff Voltage 10V
Peak Pulse Current 2.564kA
Clamping Voltage 23.4V
Max Reverse Leakage Current 5μA
Current - Peak Pulse (10/1000μs) 2564A 2.564kA 8/20μs
Power - Peak Pulse 5000W 5kW
Power Line Protection No
Case Connection ISOLATED
Element Configuration Single
Leakage Current 5μA
Polarity Unidirectional
Number of Elements 1
Operating Supply Voltage 10V
JESD-30 Code O-PALF-W2
Pin Count 2
Base Part Number BZW50
Terminal Form WIRE
Technology AVALANCHE
Max Power Dissipation 5kW
Subcategory Transient Suppressors
Capacitance 24nF
Additional Feature UL RECOGNIZED
Applications General Purpose
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series BZW50, TRANSIL?
Packaging Tape & Box (TB)
Physical
Diode Element Material SILICON
Number of Pins 6
Package / Case R6, Axial
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status NRND (Last Updated: 7 months ago)
Factory Lead Time 30 Weeks
