BZW06-48B
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 47.8VWM 100VC DO15
PDF
/
Inventory: 2236
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-204AC, DO-15, Axial
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Box (TB)
Series BZW06, TRANSIL?
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Axial
ECCN Code EAR99
Type Zener
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Applications General Purpose
Additional Feature UL RECOGNIZED
Capacitance 700pF
Subcategory Transient Suppressors
Power Rating 600W
Voltage - Rated DC 48V
Max Power Dissipation 1.7W
Technology AVALANCHE
Terminal Form WIRE
Base Part Number BZW06
Pin Count 2
Operating Supply Voltage 47.8V
Number of Elements 1
Polarity Bidirectional
Leakage Current 1μA
Element Configuration Single
Power Dissipation 1.7W
Case Connection ISOLATED
Power Line Protection No
Current - Peak Pulse (10/1000μs) 40A 8/20μs
Max Reverse Leakage Current 1μA
Clamping Voltage 100V
Peak Pulse Current 40A
Reverse Standoff Voltage 47.8V
Max Surge Current 7.8A
Peak Pulse Power 600W
Direction Bidirectional
Test Current 1mA
Breakdown Voltage 53.2V
Capacitance @ Frequency 350pF @ 1MHz
Reverse Breakdown Voltage 53.2V
Max Breakdown Voltage 53.2V
Dimensions
Diameter 3.53 mm
Length 6.75mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
