BZW06-19BRL
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 18.8VWM 39.3VC DO15
PDF
/
Inventory: 4358
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 6.75mm
Diameter 3.53mm
Technical
Reverse Breakdown Voltage 20.9V
Capacitance @ Frequency 675pF @ 1MHz
Breakdown Voltage 20.9V
Test Current 1mA
Peak Pulse Power 600W
Max Surge Current 1mA
Reverse Standoff Voltage 18.8V
Peak Pulse Current 102A
Clamping Voltage 39.3V
Current - Peak Pulse (10/1000μs) 102A 8/20μs
Power Line Protection No
Case Connection ISOLATED
Leakage Current 1μA
Configuration SINGLE
Polarity Bidirectional
Number of Elements 1
Operating Supply Voltage 18.8V
Pin Count 2
Base Part Number BZW06
Terminal Form WIRE
Technology AVALANCHE
Voltage - Rated DC 19V
Power Rating 600W
Subcategory Transient Suppressors
Capacitance 1.35nF
Additional Feature UL RECOGNIZED
Applications General Purpose
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn) - annealed
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series BZW06, TRANSIL?
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-204AC, DO-15, Axial
Mounting Type Through Hole
Mount Through Hole
