BZW04-7V8BRL
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Circuit Protection / TVS - Diodes
Description
Diode TVS Single Bi-Dir 2-Pin DO-15 T/R
PDF
/
Inventory: 3563
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Reverse Current-Max 50μA
Non-rep Peak Rev Power Dis-Max 400W
Rep Pk Reverse Voltage-Max 7.8V
Bidirectional Channels 1
Breakdown Voltage 9.1V
Voltage - Reverse Standoff (Typ) 7.8V
Voltage - Clamping (Max) @ Ipp 11.3V
Current - Peak Pulse (10/1000μs) 16A
Power - Peak Pulse 400W
Voltage - Breakdown (Min) 9.5V
Power Line Protection No
Case Connection ISOLATED
Configuration SINGLE
Polarity Bidirectional
Number of Elements 1
Pin Count 2
Base Part Number BZW04
Terminal Form WIRE
Technology AVALANCHE
Subcategory Transient Suppressors
Additional Feature UL RECOGNIZED
Applications General Purpose
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Series BZW04, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature 175°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-204AC, DO-15, Axial
Mounting Type Through Hole
Mount Through Hole
