BZW04-5V8
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 5.8VWM 13.4VC DO15
PDF
/
Buying Options
Total Price: USD $0.43
Unit Price: USD $0.4312
≥1 USD $0.4312
≥10 USD $0.32208
≥100 USD $0.2904
≥500 USD $0.20064
≥1000 USD $0.16896
≥3000 USD $0.137262
Inventory: 1445
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Length 6.75mm
Diameter 3.53 mm
Technical
Number of Unidirectional Channels 1
Reverse Breakdown Voltage 6.45V
Capacitance @ Frequency 3500pF @ 1MHz
Breakdown Voltage 6.45V
Test Current 10mA
Direction Unidirectional
Peak Pulse Power 400W
Max Surge Current 38A
Reverse Standoff Voltage 5.8V
Peak Pulse Current 174A
Clamping Voltage 13.4V
Voltage - Clamping (Max) @ Ipp 10.5V
Max Reverse Leakage Current 1mA
Power Line Protection No
Case Connection ISOLATED
Power Dissipation 400W
Element Configuration Single
Leakage Current 1mA
Polarity Bidirectional, Unidirectional
Number of Elements 1
Operating Supply Voltage 5.8V
Pin Count 2
Base Part Number BZW04
Terminal Form WIRE
Technology AVALANCHE
Max Power Dissipation 400W
Voltage - Rated DC 5.8V
Power Rating 400W
Subcategory Transient Suppressors
Capacitance 3.5nF
Additional Feature UL RECOGNIZED
Applications General Purpose
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Type Zener
ECCN Code EAR99
Termination Axial
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series BZW04, TRANSIL?
Packaging Tape & Box (TB)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-204AC, DO-15, Axial
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 11 Weeks
