BZW04-13B
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 12.8VWM 27.2VC DO15
PDF
/
Buying Options
Total Price: USD $0.34
Unit Price: USD $0.3432
≥1 USD $0.3432
≥10 USD $0.2684
≥100 USD $0.161304
≥500 USD $0.149318
≥1000 USD $0.101534
≥3000 USD $0.093474
Inventory: 1413
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-204AC, DO-15, Axial
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Box (TB)
Series BZW04, TRANSIL?
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Applications General Purpose
Additional Feature UL RECOGNIZED
Capacitance 1.2nF
Subcategory Transient Suppressors
Power Rating 400W
Voltage - Rated DC 13V
Technology AVALANCHE
Terminal Form WIRE
Base Part Number BZW04
Pin Count 2
Operating Supply Voltage 12.8V
Number of Elements 1
Leakage Current 5μA
Element Configuration Single
Power Dissipation 1.7W
Case Connection ISOLATED
Power Line Protection No
Max Reverse Leakage Current 5μA
Voltage - Clamping (Max) @ Ipp 21.2V
Clamping Voltage 27.2V
Peak Pulse Current 85A
Reverse Standoff Voltage 12.8V
Max Surge Current 19A
Peak Pulse Power 400W
Direction Bidirectional
Test Current 1mA
Breakdown Voltage 14.3V
Capacitance @ Frequency 600pF @ 1MHz
Reverse Breakdown Voltage 14.3V
Max Breakdown Voltage 14.3V
Dimensions
Diameter 3.53 mm
Height 3.53mm
Length 6.75mm
Width 3.53mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
