1.5KE7V5CARL

STMicroelectronics
RoHS
RoHS RoHS compliant
Package DO-201AA, DO-27, Axial
Category Circuit Protection / TVS - Diodes
Description TVS DIODE 6.4VWM 14.5VC DO201
PDF
/
Inventory: 6879
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Reverse Breakdown Voltage 7.13V
Capacitance @ Frequency 4250pF @ 1MHz
Breakdown Voltage 7.13V
Test Current 10mA
Peak Pulse Power 1.5kW
Max Surge Current 1mA
Reverse Standoff Voltage 6.4V
Peak Pulse Current 690A
Clamping Voltage 14.5V
Current - Peak Pulse (10/1000μs) 690A 8/20μs
Power - Peak Pulse 1500W 1.5kW
Power Line Protection No
Case Connection ISOLATED
Power Dissipation-Max 5W
Leakage Current 500μA
Configuration SINGLE
Polarity Bidirectional
Number of Elements 1
Operating Supply Voltage 6.4V
Pin Count 2
Base Part Number 1.5KE
Terminal Form WIRE
Technology AVALANCHE
Subcategory Transient Suppressors
Capacitance 8.5nF
Additional Feature UL RECOGNIZED
Applications General Purpose
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Terminal Finish MATTE TIN
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series 1.5KE, TRANSIL?
Packaging Tape & Reel (TR)

Physical

Diode Element Material SILICON
Number of Pins 2
Package / Case DO-201AA, DO-27, Axial
Mounting Type Through Hole
Mount Through Hole
