1.5KE39ARL
RoHS
RoHS compliant
RoHS compliantPackage DO-201AA, DO-27, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 33.3VWM 69.7VC DO201
PDF
/
Buying Options
Total Price: USD $0.64
Unit Price: USD $0.6424
≥1 USD $0.6424
≥10 USD $0.55528
≥100 USD $0.38456
≥500 USD $0.321323
Inventory: 1595
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Reverse Breakdown Voltage 37.1V
Capacitance @ Frequency 2400pF @ 1MHz
Breakdown Voltage 37.1V
Test Current 1mA
Peak Pulse Power 1.5kW
Max Surge Current 143A
Reverse Standoff Voltage 33.3V
Peak Pulse Current 143A
Clamping Voltage 69.7V
Max Reverse Leakage Current 1μA
Current - Peak Pulse (10/1000μs) 143A 8/20μs
Power - Peak Pulse 1500W 1.5kW
Power Line Protection No
Case Connection ISOLATED
Element Configuration Single
Leakage Current 1μA
Polarity Unidirectional
Number of Elements 1
Operating Supply Voltage 33.3V
Pin Count 2
Base Part Number 1.5KE
Terminal Form WIRE
Technology AVALANCHE
Max Power Dissipation 1.5kW
Subcategory Transient Suppressors
Capacitance 2.4nF
Additional Feature UL RECOGNIZED
Applications General Purpose
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Type Zener
Termination Axial
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series 1.5KE, TRANSIL?
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-201AA, DO-27, Axial
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 9 Weeks
