1.5KE350A
RoHS
RoHS compliant
RoHS compliantPackage DO-201AA, DO-27, Axial
Category Circuit Protection / TVS - Diodes
Description
DO-201AA DO-27Axial 1.5KE TRANSIL? 1 Through Hole Zener Tvs Diode 332V 16A 8/20mus 5.3mm 1.5kW
PDF
/
Buying Options
Total Price: USD $0.6
Unit Price: USD $0.5984
≥1 USD $0.5984
≥10 USD $0.49192
≥100 USD $0.382888
Inventory: 1858
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 5.3mm
Length 9.5mm
Height 5.3mm
Diameter 5.3mm
Technical
Number of Unidirectional Channels 1
Max Breakdown Voltage 368V
Reverse Breakdown Voltage 332V
Capacitance @ Frequency 430pF @ 1MHz
Breakdown Voltage 332V
Test Current 1mA
Peak Pulse Power 1.5kW
Max Surge Current 1mA
Reverse Standoff Voltage 299V
Peak Pulse Current 16A
Clamping Voltage 618V
Max Reverse Leakage Current 1μA
Current - Peak Pulse (10/1000μs) 16A 8/20μs
Power - Peak Pulse 1500W 1.5kW
Power Line Protection No
Case Connection ISOLATED
Power Dissipation 5W
Element Configuration Single
Leakage Current 1μA
Polarity Unidirectional
Number of Elements 1
Operating Supply Voltage 299V
Pin Count 2
Base Part Number 1.5KE
Terminal Form WIRE
Technology AVALANCHE
Voltage - Rated DC 350V
Power Rating 1.5kW
Subcategory Transient Suppressors
Capacitance 430pF
Additional Feature UL RECOGNIZED
Applications General Purpose
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn) - annealed
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series 1.5KE, TRANSIL?
Packaging Tape & Box (TB)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-201AA, DO-27, Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
