1.5KE33CARL
RoHS
RoHS compliant
RoHS compliantPackage DO-201AA, DO-27, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 28.2VWM 59VC DO201
PDF
/
Inventory: 1520
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 5.3mm
Length 9.5mm
Height 5.3mm
Diameter 5.3 mm
Technical
Reverse Breakdown Voltage 31.4V
Capacitance @ Frequency 1350pF @ 1MHz
Breakdown Voltage 31.4V
Test Current 1mA
Peak Pulse Power 1.5kW
Max Surge Current 1mA
Reverse Standoff Voltage 28.2V
Peak Pulse Current 169A
Clamping Voltage 59V
Max Reverse Leakage Current 1μA
Current - Peak Pulse (10/1000μs) 169A 8/20μs
Power - Peak Pulse 1500W 1.5kW
Power Line Protection No
Case Connection ISOLATED
Element Configuration Single
Leakage Current 1μA
Polarity Bidirectional
Number of Elements 1
Operating Supply Voltage 28.2V
Pin Count 2
Base Part Number 1.5KE
Terminal Form WIRE
Technology AVALANCHE
Max Power Dissipation 1.5kW
Voltage - Rated DC 33V
Power Rating 1.5kW
Subcategory Transient Suppressors
Capacitance 2.7nF
Additional Feature UL RECOGNIZED
Applications General Purpose
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Type Zener
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series 1.5KE, TRANSIL?
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-201AA, DO-27, Axial
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
