1.5KE22CA
RoHS
RoHS compliant
RoHS compliantPackage DO-201AA, DO-27, Axial
Category Circuit Protection / TVS - Diodes
Description
DO-201AA DO-27Axial 1.5KE TRANSIL? 1 Through Hole Zener Tvs Diode 20.9V 254A 8/20mus 5.3mm 1.5kW
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5544
≥1 USD $0.5544
≥10 USD $0.48136
≥100 USD $0.332992
≥500 USD $0.278274
Inventory: 1496
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-201AA, DO-27, Axial
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Box (TB)
Series 1.5KE, TRANSIL?
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
Termination Axial
ECCN Code EAR99
Type Zener
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Applications General Purpose
Additional Feature UL RECOGNIZED
Capacitance 3.7nF
Subcategory Transient Suppressors
Power Rating 1.5kW
Voltage - Rated DC 22V
Technology AVALANCHE
Terminal Form WIRE
Base Part Number 1.5KE
Pin Count 2
Operating Supply Voltage 18.8V
Number of Elements 1
Polarity Bidirectional
Leakage Current 1μA
Element Configuration Single
Power Dissipation 5W
Case Connection ISOLATED
Power Line Protection No
Power - Peak Pulse 1500W 1.5kW
Current - Peak Pulse (10/1000μs) 254A 8/20μs
Max Reverse Leakage Current 1μA
Clamping Voltage 39.3V
Peak Pulse Current 254A
Reverse Standoff Voltage 18.8V
Max Surge Current 1mA
Peak Pulse Power 1.5kW
Test Current 1mA
Breakdown Voltage 20.9V
Capacitance @ Frequency 1850pF @ 1MHz
Reverse Breakdown Voltage 20.9V
Max Breakdown Voltage 23.1V
Dimensions
Diameter 5.3mm
Height 5.3mm
Length 9.5mm
Width 5.3mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
