1.5KE220ARL
RoHS
RoHS compliant
RoHS compliantPackage DO-201AA, DO-27, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 188VWM 388VC DO201
PDF
/
Inventory: 1660
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-201AA, DO-27, Axial
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Cut Tape (CT)
Series 1.5KE, TRANSIL?
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Applications General Purpose
Additional Feature UL RECOGNIZED
Capacitance 625pF
Subcategory Transient Suppressors
Power Rating 1.5kW
Voltage - Rated DC 220V
Max Power Dissipation 1.5kW
Technology AVALANCHE
Terminal Form WIRE
Base Part Number 1.5KE
Pin Count 2
Operating Supply Voltage 188V
Number of Elements 1
Polarity Unidirectional
Configuration SINGLE
Leakage Current 1μA
Case Connection ISOLATED
Power Line Protection No
Power - Peak Pulse 1500W 1.5kW
Current - Peak Pulse (10/1000μs) 26A 8/20μs
Max Reverse Leakage Current 1μA
Clamping Voltage 388V
Peak Pulse Current 26A
Reverse Standoff Voltage 188V
Max Surge Current 1mA
Peak Pulse Power 1.5kW
Test Current 1mA
Breakdown Voltage 209V
Capacitance @ Frequency 625pF @ 1MHz
Reverse Breakdown Voltage 209V
Number of Unidirectional Channels 1
Dimensions
Diameter 5.3mm
Length 9.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
