1.5KE18CARL
RoHS
RoHS compliant
RoHS compliantPackage DO-201AA, DO-27, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 15.3VWM 32.5VC DO201
PDF
/
Buying Options
Total Price: USD $0.57
Unit Price: USD $0.573473
≥1 USD $0.573473
≥10 USD $0.54102
≥100 USD $0.510394
≥500 USD $0.481502
≥1000 USD $0.454246
Inventory: 1440
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Max Breakdown Voltage 18.9V
Reverse Breakdown Voltage 17.1V
Capacitance @ Frequency 2150pF @ 1MHz
Bidirectional Channels 1
Breakdown Voltage 17.1V
Test Current 1mA
Peak Pulse Power 1.5kW
Max Surge Current 1mA
Reverse Standoff Voltage 15.3V
Peak Pulse Current 308A
Clamping Voltage 32.5V
Max Reverse Leakage Current 1μA
Current - Peak Pulse (10/1000μs) 308A 8/20μs
Power - Peak Pulse 1500W 1.5kW
Power Line Protection No
Case Connection ISOLATED
Power Dissipation 1.5kW
Element Configuration Single
Leakage Current 1μA
Polarity Bidirectional
Number of Elements 1
Operating Supply Voltage 15.3V
Pin Count 2
Base Part Number 1.5KE
Terminal Form WIRE
Technology AVALANCHE
Max Power Dissipation 1.5kW
Subcategory Transient Suppressors
Capacitance 4.3nF
Additional Feature UL RECOGNIZED
Applications General Purpose
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Terminal Finish MATTE TIN
Type Zener
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
JESD-609 Code e3
Series 1.5KE, TRANSIL?
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-201AA, DO-27, Axial
Mounting Type Through Hole
Mount Through Hole
