1.5KE150A
RoHS
RoHS compliant
RoHS compliantPackage DO-201AA, DO-27, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 128VWM 265VC DO201
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.264
≥1 USD $0.264
Inventory: 585
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-201AA, DO-27, Axial
Number of Pins 2
Weight 4.535924g
Diode Element Material SILICON
Technical
Packaging Tape & Box (TB)
Series 1.5KE, TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Through Hole
ECCN Code EAR99
Type Zener
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Applications General Purpose
Additional Feature UL RECOGNIZED
Capacitance 850pF
Subcategory Transient Suppressors
Power Rating 1.5kW
Voltage - Rated DC 150V
Technology AVALANCHE
Terminal Form WIRE
Base Part Number 1.5KE
Pin Count 2
Operating Supply Voltage 128V
Number of Elements 1
Polarity Unidirectional
Leakage Current 1μA
Element Configuration Single
Power Dissipation 5W
Case Connection ISOLATED
Power Line Protection No
Power - Peak Pulse 1500W 1.5kW
Current - Peak Pulse (10/1000μs) 38A 8/20μs
Max Reverse Leakage Current 1μA
Clamping Voltage 265V
Peak Pulse Current 38A
Reverse Standoff Voltage 128V
Max Surge Current 1mA
Peak Pulse Power 1.5kW
Test Current 1mA
Breakdown Voltage 143V
Capacitance @ Frequency 850pF @ 1MHz
Reverse Breakdown Voltage 143V
Max Breakdown Voltage 158V
Number of Unidirectional Channels 1
Dimensions
Diameter 5.3 mm
Height 5.3mm
Length 9.5mm
Width 5.3mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
