1.5KE12ARL
RoHS
RoHS compliant
RoHS compliantPackage DO-201AA, DO-27, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 10.2VWM 21.7VC DO201
PDF
/
Inventory: 2939
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 9.5mm
Diameter 5.3mm
Technical
Reverse Breakdown Voltage 11.4V
Capacitance @ Frequency 6000pF @ 1MHz
Breakdown Voltage 11.4V
Test Current 1mA
Peak Pulse Power 1.5kW
Max Surge Current 461A
Reverse Standoff Voltage 10.2V
Peak Pulse Current 461A
Clamping Voltage 21.7V
Max Reverse Leakage Current 5μA
Current - Peak Pulse (10/1000μs) 461A 8/20μs
Power - Peak Pulse 1500W 1.5kW
Power Line Protection No
Case Connection ISOLATED
Power Dissipation-Max 5W
Leakage Current 5μA
Configuration SINGLE
Polarity Unidirectional
Number of Elements 1
Operating Supply Voltage 12V
Pin Count 2
Base Part Number 1.5KE
Terminal Form WIRE
Technology AVALANCHE
Voltage - Rated DC 12V
Power Rating 1.5kW
Subcategory Transient Suppressors
Capacitance 6nF
Additional Feature UL RECOGNIZED
Applications General Purpose
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Type Zener
ECCN Code EAR99
Termination Axial
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series 1.5KE, TRANSIL?
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-201AA, DO-27, Axial
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
