SMBJ8V0A
RoHS
/
Package /
Category Circuit Protection / TVS - Diodes
Description
1 Surface Mount TRANS VOLTAGE SUPPRESSOR DIODE AVALANCHE (Type) Tvs Diode 13.6V 50muA 600W 150C
PDF
/
Buying Options
Total Price: USD $0.1
Unit Price: USD $0.0968
≥1 USD $0.0968
Inventory: 21563
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 3.95mm
Length 4.75mm
Height 2.45mm
Technical
Voltage - Clamping 13.6V
Voltage - Breakdown 8.89V
Current - Leakage 50μA
Reverse Breakdown Voltage 8.89V
Rep Pk Reverse Voltage-Max 8V
Breakdown Voltage 9.36V
Peak Pulse Power 600W
Max Surge Current 44.1A
Reverse Standoff Voltage 8V
Peak Pulse Current 44.1A
Max Reverse Leakage Current 50μA
Current - Test 1mA
Voltage - Breakdown (Min) 8.89V
Power Line Protection No
Diode Type TRANS VOLTAGE SUPPRESSOR DIODE
Element Configuration Single
Power Dissipation-Max 600W
Polarity Unidirectional
Number of Elements 1
Operating Supply Voltage 8V
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Voltage - Rated DC 8V
Power Rating 600W
Subcategory Transient Suppressors
Additional Feature UL RECOGNIZED
Composition Zener
Min Operating Temperature -55°C
Max Operating Temperature 150°C
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
Published 2017
Physical
Diode Element Material SILICON
Weight 180mg
Number of Pins 2
Mount Surface Mount
