ESD7951ST5G
RoHS
RoHS compliant
RoHS compliantPackage SOD-923
Category Circuit Protection / TVS - Diodes
Description
ESD Suppressor TVS 5V Automotive 2-Pin SOD-923 T/R
PDF
/
Buying Options
Total Price: USD $0.03
Unit Price: USD $0.030349
≥1 USD $0.030349
≥10 USD $0.025115
≥100 USD $0.022499
≥500 USD $0.020537
≥1000 USD $0.015236
≥20000 USD $0.014451
Inventory: 57667
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Contact Plating Tin
Mounting Type Surface Mount
Package / Case SOD-923
Surface Mount YES
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -55°C~125°C TJ
Packaging Tape & Reel (TR)
Published 2008
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Zener
Applications USB
Capacitance 900FF
Subcategory Transient Suppressors
Max Power Dissipation 150mW
Technology AVALANCHE
Terminal Position DUAL
Terminal Form FLAT
Depth 600μm
Base Part Number ESD7951
Pin Count 2
Operating Supply Voltage 5V
Number of Elements 1
Working Voltage 5V
Polarity Bidirectional
Number of Channels 1
Leakage Current 1μA
Element Configuration Single
Power Line Protection No
Current - Peak Pulse (10/1000μs) 1A 8/20μs
Max Reverse Leakage Current 1μA
Clamping Voltage 12.9V
Voltage - Reverse Standoff (Typ) 5V Max
Peak Pulse Current 1A
Reverse Standoff Voltage 5V
Peak Pulse Power 150mW
Halogen Free Halogen Free
Test Current 1mA
Breakdown Voltage 5.4V
Rep Pk Reverse Voltage-Max 5V
Capacitance @ Frequency 0.5pF @ 1MHz
ESD Protection Yes
Dimensions
Height 400μm
Length 800μm
Width 650μm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
