1V5KE68A
RoHS
/
Package /
Category Circuit Protection / TVS - Diodes
Description
Tape & Reel (TR) 1 Through Hole TRANS VOLTAGE SUPPRESSOR DIODE (Type) Tvs Diode 92V 5muA 5.33mm 1.5kW
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.26885
≥1 USD $0.26885
≥10 USD $0.2204
≥100 USD $0.21375
≥500 USD $0.2071
≥1000 USD $0.1995
Inventory: 1105
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Tin
Mount Through Hole
Number of Pins 2
Weight 360mg
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 2016
Pbfree Code yes
Part Status Active
Number of Terminations 2
Termination Axial
ECCN Code EAR99
Max Operating Temperature 175°C
Min Operating Temperature -55°C
Composition Zener
Additional Feature UL RECOGNIZED
Subcategory Transient Suppressors
Power Rating 1.5kW
Voltage - Rated DC 68V
Technology AVALANCHE
Terminal Form WIRE
Operating Supply Voltage 58.1V
Number of Elements 1
Polarity Unidirectional
Power Dissipation-Max 1.5kW
Element Configuration Single
Diode Type TRANS VOLTAGE SUPPRESSOR DIODE
Power Dissipation 5W
Case Connection ISOLATED
Voltage - Breakdown (Min) 64.6V
Current - Test 1mA
Max Reverse Leakage Current 5μA
Peak Pulse Current 16.3A
Reverse Standoff Voltage 58.1V
Max Surge Current 16.3A
Peak Pulse Power 1.5kW
Breakdown Voltage 68V
Reverse Breakdown Voltage 64.6V
Current - Leakage 5μA
Max Breakdown Voltage 71.4V
Voltage - Breakdown 64.6V
Voltage - Clamping 92V
Dimensions
Diameter 5.33mm
Length 9.53mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
