MXLSMLJ90A
RoHS
/
Package DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 90V 146V DO214AB
PDF
/
Buying Options
Total Price: USD $13.41
Unit Price: USD $13.408648
≥1 USD $13.408648
≥200 USD $5.189894
≥500 USD $5.007401
≥1000 USD $4.916811
Inventory: 3739
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Non-rep Peak Rev Power Dis-Max 3000W
Rep Pk Reverse Voltage-Max 90V
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 90V
Voltage - Clamping (Max) @ Ipp 146V
Current - Peak Pulse (10/1000μs) 20.6A
Power - Peak Pulse 3000W 3kW
Voltage - Breakdown (Min) 100V
Power Line Protection No
Configuration SINGLE
Polarity UNIDIRECTIONAL
Number of Elements 1
JESD-30 Code R-PDSO-J2
Terminal Form J BEND
Terminal Position DUAL
Technology AVALANCHE
Additional Feature HIGH RELIABILITY
Applications General Purpose
Terminal Finish TIN LEAD
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Series Military, MIL-PRF-19500
Packaging Bulk
Operating Temperature -65°C~150°C TJ
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time 18 Weeks
