MXLSMLJ70AE3
RoHS
/
Package DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 70V 113V DO214AB
PDF
/
Inventory: 5228
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Non-rep Peak Rev Power Dis-Max 3000W
Rep Pk Reverse Voltage-Max 70V
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 70V
Voltage - Clamping (Max) @ Ipp 113V
Current - Peak Pulse (10/1000μs) 26.6A
Power - Peak Pulse 3000W 3kW
Voltage - Breakdown (Min) 77.8V
Power Line Protection No
Configuration SINGLE
Polarity UNIDIRECTIONAL
Number of Elements 1
JESD-30 Code R-PDSO-J2
Pin Count 2
Terminal Form J BEND
Terminal Position DUAL
Technology AVALANCHE
Additional Feature HIGH RELIABILITY
Applications General Purpose
Terminal Finish MATTE TIN
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Military, MIL-PRF-19500
Published 1997
Packaging Bulk
Operating Temperature -65°C~150°C TJ
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 2 weeks ago)
Factory Lead Time 18 Weeks
