MXLSMBJ26AE3
RoHS
/
Package DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description
Diode TVS Single Uni-Dir 26V 600W 2-Pin DO-214AA
PDF
/
Inventory: 4614
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Breakdown Voltage 30.4V
Unidirectional Channels 1
Test Current 1mA
Direction Unidirectional
Peak Pulse Power 600W
Reverse Standoff Voltage 26V
Peak Pulse Current 14.2A
Clamping Voltage 42.1V
Max Reverse Leakage Current 1μA
Power - Peak Pulse 600W
Voltage - Breakdown (Min) 28.9V
Power Line Protection No
Element Configuration Single
Number of Elements 1
Pin Count 2
Terminal Form J BEND
Terminal Position DUAL
Technology AVALANCHE
Subcategory Transient Suppressors
Additional Feature HIGH RELIABILITY
Applications General Purpose
Terminal Finish MATTE TIN
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Military, MIL-PRF-19500
Published 1997
Packaging Bulk
Operating Temperature -65°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
