MXLSMBG18CAE3
RoHS
/
Package DO-215AA, SMB Gull Wing
Category Circuit Protection / TVS - Diodes
Description
Diode TVS Single Bi-Dir 18V 600W 2-Pin DO-215AA
PDF
/
Inventory: 5443
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Bidirectional Channels 1
Breakdown Voltage 21.05V
Test Current 1mA
Direction Bidirectional
Peak Pulse Power 600W
Reverse Standoff Voltage 18V
Peak Pulse Current 20.5A
Clamping Voltage 29.2V
Max Reverse Leakage Current 1μA
Power - Peak Pulse 600W
Voltage - Breakdown (Min) 20V
Power Line Protection No
Element Configuration Single
Number of Elements 1
Pin Count 2
Terminal Position DUAL
Technology AVALANCHE
Subcategory Transient Suppressors
Additional Feature HIGH RELIABILITY
Applications General Purpose
Terminal Finish MATTE TIN
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Military, MIL-PRF-19500
Published 1997
Packaging Bulk
Operating Temperature -65°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-215AA, SMB Gull Wing
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
