MSMCJ85AE3
RoHS
/
Package DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 85V 137V DO214AB
PDF
/
Inventory: 4438
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Physical
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Surface Mount YES
Diode Element Material SILICON
Technical
Operating Temperature -65°C~150°C TJ
Packaging Bulk
Published 1997
Series Military, MIL-PRF-19500
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Additional Feature HIGH RELIABILITY
Technology AVALANCHE
Terminal Position DUAL
Terminal Form J BEND
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 40
Pin Count 2
JESD-30 Code R-PDSO-J2
Number of Elements 1
Polarity UNIDIRECTIONAL
Configuration SINGLE
Power Line Protection No
Voltage - Breakdown (Min) 94.4V
Power - Peak Pulse 1500W 1.5kW
Current - Peak Pulse (10/1000μs) 10.4A
Voltage - Clamping (Max) @ Ipp 137V
Voltage - Reverse Standoff (Typ) 85V
Unidirectional Channels 1
Rep Pk Reverse Voltage-Max 85V
Compliance
RoHS Status Non-RoHS Compliant
