1N6071A
RoHS
/
Package DO-13
Category Circuit Protection / TVS - Diodes
Description
Diode TVS Single Bi-Dir 170V 1.5KW 2-Pin DO-13
PDF
/
Inventory: 2219
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Reverse Breakdown Voltage 190V
Test Current 1mA
Peak Pulse Power 1.5kW
Reverse Standoff Voltage 170V
Peak Pulse Current 5.1A
Clamping Voltage 294V
Current - Peak Pulse (10/1000μs) 5.1A
Power - Peak Pulse 1500W 1.5kW
Voltage - Breakdown (Min) 190V
Power Line Protection No
Case Connection ISOLATED
Element Configuration Single
Power Dissipation-Max 1W
Leakage Current 5μA
Polarity Bidirectional
Number of Elements 1
Pin Count 2
Terminal Form WIRE
Terminal Position AXIAL
Technology AVALANCHE
Applications General Purpose
Terminal Finish Tin/Lead (Sn/Pb)
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Packaging Bulk
Operating Temperature -55°C~175°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-13
Mounting Type Through Hole
Mount Through Hole
Contact Plating Lead, Tin
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 7 Weeks
