1.5KE91CA-TP
RoHS
RoHS compliant
RoHS compliantPackage DO-201AE, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 77.8V 125V DO201AE
PDF
/
Inventory: 2647
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Through Hole
Package / Case DO-201AE, Axial
Surface Mount NO
Diode Element Material SILICON
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Additional Feature CMOS COMPATIBLE, UL RECOGNIZED
Subcategory Transient Suppressors
Technology AVALANCHE
Terminal Form WIRE
Base Part Number 1.5KE
Pin Count 2
JESD-30 Code O-PALF-W2
Number of Elements 1
Polarity BIDIRECTIONAL
Configuration SINGLE
Power Dissipation-Max 5W
Case Connection ISOLATED
Power Line Protection No
Voltage - Breakdown (Min) 86.5V
Power - Peak Pulse 1500W 1.5kW
Voltage - Clamping (Max) @ Ipp 125V
Voltage - Reverse Standoff (Typ) 77.8V
Breakdown Voltage 91V
Bidirectional Channels 1
Rep Pk Reverse Voltage-Max 77.8V
Compliance
RoHS Status ROHS3 Compliant
