TPSMD60A
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 60V 96.8V DO214AB
PDF
/
Buying Options
Total Price: USD $0.75
Unit Price: USD $0.750495
≥1 USD $0.750495
≥10 USD $0.708021
≥100 USD $0.667938
≥500 USD $0.630132
≥1000 USD $0.594467
Inventory: 7270
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Non-rep Peak Rev Power Dis-Max 3000W
Rep Pk Reverse Voltage-Max 60V
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 60V
Voltage - Clamping (Max) @ Ipp 96.8V
Current - Peak Pulse (10/1000μs) 31A
Power - Peak Pulse 3000W 3kW
Voltage - Breakdown (Min) 66.7V
Power Line Protection No
Power Dissipation-Max 6.5W
Configuration SINGLE
Polarity UNIDIRECTIONAL
Number of Elements 1
JESD-30 Code R-PDSO-J2
Terminal Form J BEND
Terminal Position DUAL
Technology AVALANCHE
Additional Feature EXCELLENT CLAMPING CAPABILITY, HIGH RELIABILITY, UL RECOGNIZED
Applications Automotive
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, TPSMD
Published 2016
Packaging Tape & Reel (TR)
Operating Temperature -65°C~150°C TJ
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
