SMF4L8.0A
RoHS
RoHS compliant
RoHS compliantPackage SOD-123F
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 8V 13.6V SOD123FL
PDF
/
Buying Options
Total Price: USD $0.34
Unit Price: USD $0.340666
≥1 USD $0.340666
≥10 USD $0.321378
≥100 USD $0.303194
≥500 USD $0.286033
≥1000 USD $0.269839
Inventory: 1140
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Non-rep Peak Rev Power Dis-Max 2000W
Rep Pk Reverse Voltage-Max 8V
Breakdown Voltage 8.89V
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 8V
Voltage - Clamping (Max) @ Ipp 13.6V
Current - Peak Pulse (10/1000μs) 27.2A
Power - Peak Pulse 400W
Power Line Protection No
Configuration SINGLE
Polarity UNIDIRECTIONAL
Number of Elements 1
JESD-30 Code R-PDSO-F2
Terminal Form FLAT
Terminal Position DUAL
Technology AVALANCHE
Applications General Purpose
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series SMF4L
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case SOD-123F
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 19 Weeks
