SMDJ15A-HRA
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
Diode TVS Single Uni-Dir 15V 3KW 2-Pin SMC T/R
PDF
/
Inventory: 5430
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -65°C~150°C TJ
Packaging Tape & Reel (TR)
Published 2013
Series SMDJ-HRA
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Additional Feature EXCELLENT CLAMPING CAPABILITY, HIGH RELIABILITY, UL RECOGNIZED
Technology AVALANCHE
Terminal Position DUAL
Terminal Form J BEND
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 40
Number of Elements 1
Polarity Unidirectional
Configuration SINGLE
Leakage Current 2μA
Power Dissipation-Max 6.5W
Power Line Protection No
Power - Peak Pulse 3000W 3kW
Current - Peak Pulse (10/1000μs) 123A
Voltage - Clamping (Max) @ Ipp 24.4V
Clamping Voltage 24.4V
Peak Pulse Current 123A
Reverse Standoff Voltage 15V
Peak Pulse Power 3kW
Test Current 1mA
Breakdown Voltage 16.7V
Reverse Breakdown Voltage 16.7V
Non-rep Peak Rev Power Dis-Max 3000W
Number of Unidirectional Channels 1
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
