SM36-02HTG
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 36V 52V SOT23-3
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.22135
≥1 USD $0.22135
≥10 USD $0.1824
≥100 USD $0.1767
≥500 USD $0.171
≥1000 USD $0.1653
Inventory: 56550
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Number of Pins 3
Diode Element Material SILICON
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tape & Reel (TR)
Published 2013
Series Automotive, AEC-Q101, SM, SPA?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination SMD/SMT
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications Automotive
HTS Code 8541.10.00.50
Subcategory Transient Suppressors
Max Power Dissipation 400W
Technology AVALANCHE
Terminal Position DUAL
Terminal Form GULL WING
Operating Supply Voltage 36V
Number of Elements 2
Working Voltage 36V
Polarity UNIDIRECTIONAL
Power Line Protection No
Current - Peak Pulse (10/1000μs) 4A 8/20μs
Clamping Voltage 52V
Voltage - Reverse Standoff (Typ) 36V Max
Peak Pulse Current 4A
Reverse Standoff Voltage 36V
Max Surge Current 5A
Peak Pulse Power 400W
Capacitance @ Frequency 50pF @ 1MHz
Number of Unidirectional Channels 2
Dimensions
Height 1.12mm
Length 3.04mm
Width 1.4mm
Compliance
RoHS Status ROHS3 Compliant
