5KP64A
RoHS
RoHS compliant
RoHS compliantPackage P600, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 64VWM 103VC AXIAL
PDF
/
Buying Options
Total Price: USD $2.43
Unit Price: USD $2.4288
≥1 USD $2.4288
≥10 USD $2.01784
≥100 USD $1.606264
Inventory: 998
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case P600, Axial
Number of Pins 2
Supplier Device Package P600
Weight 2.099991g
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tape & Reel (TR)
Published 2009
Series 5KP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Axial
Type Zener
Max Operating Temperature 175°C
Min Operating Temperature -55°C
Composition Zener
Applications General Purpose
Power Rating 5kW
Voltage - Rated DC 64V
Max Power Dissipation 8W
Operating Supply Voltage 64V
Number of Elements 1
Polarity Unidirectional
Number of Channels 1
Leakage Current 2μA
Power Dissipation 5kW
Power Line Protection No
Voltage - Breakdown (Min) 71.1V
Power - Peak Pulse 5000W 5kW
Current - Peak Pulse (10/1000μs) 49.5A
Voltage - Clamping (Max) @ Ipp 103V
Clamping Voltage 103V
Voltage - Reverse Standoff (Typ) 64V
Peak Pulse Current 49.5A
Reverse Standoff Voltage 64V
Max Surge Current 48.6A
Peak Pulse Power 5kW
Direction Unidirectional
Test Current 5mA
Unidirectional Channels 1
Breakdown Voltage 71.1V
Reverse Breakdown Voltage 71.1V
Max Breakdown Voltage 78.6V
Number of Unidirectional Channels 1
Dimensions
Diameter 9.1mm
Length 9.1mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
