3KP64C
RoHS
RoHS compliant
RoHS compliantPackage P600, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 64VWM 108.15VC AXIAL
PDF
/
Inventory: 9707
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Number of Bidirectional Channels 1
Bidirectional Channels 1
Breakdown Voltage 71.1V
Peak Pulse Power 3kW
Max Surge Current 29.1A
Reverse Standoff Voltage 64V
Peak Pulse Current 29.1A
Voltage - Reverse Standoff (Typ) 64V
Clamping Voltage 108.15V
Voltage - Clamping (Max) @ Ipp 108.15V
Current - Peak Pulse (10/1000μs) 29.1A
Power - Peak Pulse 3000W 3kW
Voltage - Breakdown (Min) 67.37V
Power Line Protection No
Number of Channels 1
Polarity Bidirectional
Operating Supply Voltage 64V
Applications General Purpose
Composition Zener
Min Operating Temperature -55°C
Max Operating Temperature 175°C
Type Zener
Termination Axial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 3KP
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Supplier Device Package P600
Package / Case P600, Axial
Mounting Type Through Hole
Mount Through Hole
Alternative Model
