3KP150C-B
RoHS
RoHS compliant
RoHS compliantPackage P600, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 150VWM 255.15VC P600
PDF
/
Inventory: 1773
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Non-rep Peak Rev Power Dis-Max 3000W
Bidirectional Channels 1
Breakdown Voltage 176V
Peak Pulse Power 3kW
Reverse Standoff Voltage 150V
Peak Pulse Current 12.3A
Clamping Voltage 255.15V
Current - Peak Pulse (10/1000μs) 12.3A
Power - Peak Pulse 3000W 3kW
Voltage - Breakdown (Min) 158.4V
Power Line Protection No
Case Connection ISOLATED
Power Dissipation-Max 7W
Configuration SINGLE
Polarity BIDIRECTIONAL
Number of Elements 1
JESD-30 Code O-PALF-W2
Pin Count 2
Time@Peak Reflow Temperature-Max (s) 40
Peak Reflow Temperature (Cel) 260
Terminal Form WIRE
Technology AVALANCHE
Subcategory Transient Suppressors
Additional Feature UL RECOGNIZED
Applications General Purpose
Terminal Finish Matte Tin (Sn)
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series 3KP
Published 2014
Packaging Bulk
Operating Temperature -55°C~175°C TJ
Physical
Diode Element Material SILICON
Package / Case P600, Axial
Mounting Type Through Hole
Mount Through Hole
