20KPA68CA
RoHS
RoHS compliant
RoHS compliantPackage P600, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 68VWM 110VC AXIAL
PDF
/
Buying Options
Total Price: USD $10.12
Unit Price: USD $10.12
≥1 USD $10.12
Inventory: 1073
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Bidirectional Channels 1
Breakdown Voltage 76V
Peak Pulse Power 20kW
Max Surge Current 183.6A
Reverse Standoff Voltage 68V
Peak Pulse Current 183.6A
Clamping Voltage 110V
Voltage - Clamping (Max) @ Ipp 110V
Power - Peak Pulse 20000W 20kW
Power Line Protection No
Case Connection ISOLATED
Power Dissipation-Max 8W
Number of Channels 1
Configuration SINGLE
Polarity Bidirectional
Number of Elements 1
Operating Supply Voltage 68V
Pin Count 2
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Terminal Form WIRE
Technology AVALANCHE
Subcategory Transient Suppressors
Additional Feature UL RECOGNIZED
Applications General Purpose
Terminal Finish Matte Tin (Sn)
Type Zener
ECCN Code EAR99
Termination Axial
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code no
JESD-609 Code e3
Series 20KPA
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case P600, Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 17 Weeks
