20KPA32A-B
RoHS
RoHS compliant
RoHS compliantPackage P600, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 32VWM 54.3VC P600
PDF
/
Inventory: 956
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case P600, Axial
Diode Element Material SILICON
Technical
Operating Temperature -55°C~175°C TJ
Packaging Bulk
Published 2014
Series 20KPA
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Additional Feature UL RECOGNIZED
Subcategory Transient Suppressors
Technology AVALANCHE
Terminal Form WIRE
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 2
JESD-30 Code O-PALF-W2
Number of Elements 1
Polarity UNIDIRECTIONAL
Configuration SINGLE
Power Dissipation-Max 8W
Case Connection ISOLATED
Power Line Protection No
Voltage - Breakdown (Min) 35.74V
Power - Peak Pulse 20000W 20kW
Current - Peak Pulse (10/1000μs) 372A
Clamping Voltage 54.3V
Peak Pulse Current 372A
Reverse Standoff Voltage 32V
Peak Pulse Power 20kW
Unidirectional Channels 1
Non-rep Peak Rev Power Dis-Max 20000W
Compliance
RoHS Status ROHS3 Compliant
