15KPA36CA-B
RoHS
RoHS compliant
RoHS compliantPackage P600, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 36VWM 59.8VC AXIAL
PDF
/
Inventory: 6511
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case P600, Axial
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -55°C~175°C TJ
Packaging Bulk
Published 2010
Series 15KPA
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
Termination Axial
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Additional Feature EXCELLENT CLAMPING CAPABILITY, UL RECOGNIZED
Subcategory Transient Suppressors
Technology AVALANCHE
Terminal Form WIRE
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 2
Operating Supply Voltage 36V
Number of Elements 1
Polarity Bidirectional
Configuration SINGLE
Number of Channels 1
Leakage Current 2μA
Power Dissipation 15kW
Case Connection ISOLATED
Power Line Protection No
Power - Peak Pulse 15000W 15kW
Clamping Voltage 59.8V
Voltage - Reverse Standoff (Typ) 36V
Peak Pulse Current 252.5A
Reverse Standoff Voltage 36V
Max Surge Current 251A
Peak Pulse Power 15kW
Test Current 5mA
Breakdown Voltage 40V
Reverse Breakdown Voltage 40.2V
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
