15KPA33A
RoHS
RoHS compliant
RoHS compliantPackage P600, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 33VWM 54.7VC AXIAL
PDF
/
Buying Options
Total Price: USD $8.76
Unit Price: USD $8.756
≥1 USD $8.756
Inventory: 983
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case P600, Axial
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tape & Reel (TR)
Published 2009
Series 15KPA
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
Termination Axial
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Additional Feature EXCELLENT CLAMPING CAPABILITY, UL RECOGNIZED
Subcategory Transient Suppressors
Max Power Dissipation 8W
Technology AVALANCHE
Terminal Form WIRE
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 2
Operating Supply Voltage 33V
Number of Elements 1
Polarity Unidirectional
Configuration SINGLE
Leakage Current 2μA
Power Dissipation 8W
Case Connection ISOLATED
Power Line Protection No
Power - Peak Pulse 15000W 15kW
Clamping Voltage 54.7V
Voltage - Reverse Standoff (Typ) 33V
Peak Pulse Current 276.1A
Reverse Standoff Voltage 33V
Max Surge Current 274A
Peak Pulse Power 15kW
Test Current 5mA
Breakdown Voltage 36.7V
Reverse Breakdown Voltage 36.9V
Max Breakdown Voltage 40.4V
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
