1.5KE36C
RoHS
RoHS compliant
RoHS compliantPackage DO-201AA, DO-27, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 30.8VWM 52.4VC AXIAL
PDF
/
Buying Options
Total Price: USD $1.39
Unit Price: USD $1.39121
≥1 USD $1.39121
≥10 USD $0.674344
≥100 USD $0.309584
≥500 USD $0.306416
Inventory: 1296
Minimum: 1
-
+
Technical Details
Technical
Voltage - Rated DC 36V
Technology AVALANCHE
Terminal Form WIRE
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 2
JESD-30 Code O-PALF-W2
Operating Supply Voltage 30.8V
Number of Elements 1
Polarity Bidirectional
Configuration SINGLE
Number of Channels 1
Power Dissipation-Max 6.5W
Case Connection ISOLATED
Power Line Protection No
Power - Peak Pulse 1500W 1.5kW
Voltage - Clamping (Max) @ Ipp 52.4V
Clamping Voltage 52.4V
Peak Pulse Current 30.5A
Reverse Standoff Voltage 30.8V
Max Surge Current 30.5A
Peak Pulse Power 1.5kW
Breakdown Voltage 32.4V
Bidirectional Channels 1
Power Rating 1.5kW
Subcategory Transient Suppressors
Additional Feature EXCELLENT CLAMPING CAPABILITY
Applications General Purpose
Terminal Finish Matte Tin (Sn)
Type Zener
ECCN Code EAR99
Termination Axial
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series 1.5KE
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Dimensions
Diameter 5.3mm
Length 9.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Diode Element Material SILICON
Package / Case DO-201AA, DO-27, Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 19 Weeks
