DESD1FLEX2SOQ-7

Diodes Incorporated
RoHS
RoHS RoHS compliant
Package TO-236-3, SC-59, SOT-23-3
Category Circuit Protection / TVS - Diodes
Description TVS DIODE 24V 70V SOT23-3
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.3344
≥1 USD $0.3344
≥10 USD $0.2596
≥100 USD $0.156024
≥500 USD $0.144426
≥1000 USD $0.098208
Inventory: 6094
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 17 Weeks

Physical

Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Surface Mount YES
Diode Element Material SILICON

Technical

Operating Temperature -65°C~150°C TJ
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q101
JESD-609 Code e3
Part Status Active
Number of Terminations 3
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications Automotive
Additional Feature HIGH RELIABILITY
HTS Code 8541.10.00.50
Technology AVALANCHE
Terminal Position DUAL
Terminal Form GULL WING
JESD-30 Code R-PDSO-G3
Number of Elements 2
Polarity BIDIRECTIONAL
Power Dissipation-Max 0.3W
Power Line Protection No
Voltage - Breakdown (Min) 25.4V
Power - Peak Pulse 200W
Current - Peak Pulse (10/1000μs) 3A 8/20μs
Voltage - Clamping (Max) @ Ipp 70V
Voltage - Reverse Standoff (Typ) 24V Max
Bidirectional Channels 2
Capacitance @ Frequency 11pF @ 5MHz

Compliance

RoHS Status ROHS3 Compliant
