3SMC20A BK
RoHS
/
Package /
Category Circuit Protection / TVS - Diodes
Description
PDF
/
Inventory: 5213
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Breakdown Voltage-Max 25.5V
Clamping Voltage-Max 32.4V
Breakdown Voltage-Min 22.2V
Non-rep Peak Rev Power Dis-Max 3000W
Rep Pk Reverse Voltage-Max 20V
Breakdown Voltage 23.85V
Diode Type TRANS VOLTAGE SUPPRESSOR DIODE
Configuration SINGLE
Polarity UNIDIRECTIONAL
Number of Elements 1
Operating Temperature (Min) -65°C
Operating Temperature (Max) 150°C
JESD-30 Code R-PDSO-C2
Pin Count 2
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code compliant
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Subcategory Transient Suppressors
HTS Code 8541.10.00.50
Additional Feature UL RECOGNIZED
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1
Pbfree Code icon-pbfree yes
JESD-609 Code e3
Physical
Number of Terminals 2
Diode Element Material SILICON
Surface Mount YES
