1SMB130A TR13
RoHS
/
Package /
Category Circuit Protection / TVS - Diodes
Description
PDF
/
Inventory: 6239
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount YES
Diode Element Material SILICON
Number of Terminals 2
Technical
JESD-609 Code e3
Pbfree Code icon-pbfree yes
Moisture Sensitivity Level (MSL) 1
ECCN Code EAR99
Terminal Finish MATTE TIN (315)
HTS Code 8541.10.00.50
Subcategory Transient Suppressors
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) 10
JESD-30 Code R-PDSO-C2
Qualification Status Not Qualified
Operating Temperature (Max) 150°C
Operating Temperature (Min) -65°C
Number of Elements 1
Polarity UNIDIRECTIONAL
Configuration SINGLE
Diode Type TRANS VOLTAGE SUPPRESSOR DIODE
Breakdown Voltage 154.75V
Rep Pk Reverse Voltage-Max 130V
Non-rep Peak Rev Power Dis-Max 600W
Breakdown Voltage-Min 144V
Clamping Voltage-Max 209V
Breakdown Voltage-Max 165.5V
Compliance
RoHS Status RoHS Compliant
