SMAJ17CA-Q
RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 17V 27.6V SMA
PDF
/
Buying Options
Total Price: USD $0.34
Unit Price: USD $0.337841
≥1 USD $0.337841
≥10 USD $0.318717
≥100 USD $0.300681
≥500 USD $0.283664
≥1000 USD $0.267605
Inventory: 9788
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Non-rep Peak Rev Power Dis-Max 400W
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 17V
Voltage - Clamping (Max) @ Ipp 27.6V
Current - Peak Pulse (10/1000μs) 14.5A
Power - Peak Pulse 400W
Voltage - Breakdown (Min) 18.9V
Power Line Protection No
Configuration SINGLE
Polarity BIDIRECTIONAL
Number of Elements 1
JESD-30 Code R-PDSO-C2
Base Part Number SMAJ17
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Additional Feature PRSM-MIN
Applications Automotive
Terminal Finish Matte Tin (Sn)
Type Zener
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Automotive, AEC-Q101, SMAJ
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case DO-214AC, SMA
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
