P6SMB20CA

Bourns Inc.
RoHS
RoHS RoHS compliant
Package DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description TVS DIODE 17.1V 27.7V DO214AA
PDF
/
Buying Options
Total Price: USD $0.1
Unit Price: USD $0.10164
≥1 USD $0.10164
Inventory: 4798914
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Bidirectional Channels 1
Peak Pulse Power 600W
Reverse Standoff Voltage 17.1V
Peak Pulse Current 22A
Voltage - Reverse Standoff (Typ) 17.1V
Clamping Voltage 27.7V
Current - Peak Pulse (10/1000μs) 22A
Voltage - Breakdown (Min) 19V
Power Line Protection No
Configuration SINGLE
Polarity BIDIRECTIONAL
Number of Elements 1
JESD-30 Code R-PDSO-C2
Base Part Number P6SMB
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Applications General Purpose
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ

Physical

Diode Element Material SILICON
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 14 Weeks
