CDSOD323-T24SC
RoHS
RoHS compliant
RoHS compliantPackage SC-76, SOD-323
Category Circuit Protection / TVS - Diodes
Description
ESD Suppressor TVS ±30kV 2-Pin SOD-323 T/R
PDF
/
Buying Options
Total Price: USD $0.43
Unit Price: USD $0.4312
≥1 USD $0.4312
≥10 USD $0.374
≥100 USD $0.258632
≥500 USD $0.216128
≥1000 USD $0.2024
Inventory: 31936
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Length 1.9mm
Height 920μm
Technical
Capacitance @ Frequency 40pF @ 1MHz
Bidirectional Channels 1
Breakdown Voltage 26.7V
Direction Bidirectional
Peak Pulse Power 400W
Reverse Standoff Voltage 24V
Peak Pulse Current 9A
Clamping Voltage 46.2V
Voltage - Clamping (Max) @ Ipp 46.2V Typ
Current - Peak Pulse (10/1000μs) 9A 8/20μs
Power Line Protection No
Element Configuration Single
Leakage Current 1μA
Number of Channels 1
Working Voltage 24V
Number of Elements 1
Operating Supply Voltage 24V
Pin Count 2
Base Part Number CDSOD323
Depth 1.45mm
Terminal Form GULL WING
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 400W
Subcategory Transient Suppressors
Capacitance 40pF
Applications General Purpose
Terminal Finish Matte Tin (Sn)
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case SC-76, SOD-323
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
