GXF15004
RoHS
RoHS compliant
RoHS compliantPackage /
Category Capacitors / Trimmers, Variable Capacitors
Description
FILMTRIM? VARIABLE CAPACITOR variable capacitor 0.433Lx0.402W 11.00mmx10.20mm 2.5pF~15pF 200V
PDF
/
Buying Options
Total Price: USD $10.7
Unit Price: USD $10.702761
≥1 USD $10.702761
≥200 USD $4.270864
≥500 USD $4.127758
≥1000 USD $4.058174
Inventory: 7693
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Terminal Shape FLAT
Dielectric Material Polytetrafluoroethylene (PTFE)
Technical
Operating Temperature -40°C~125°C
Packaging Bulk
Published 2002
Series FILMTRIM?
Size / Dimension 0.433Lx0.402W 11.00mmx10.20mm
Feature General Purpose
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Voltage - Rated 200V
HTS Code 8532.30.00.90
Terminal Pitch 10mm
Capacitor Type VARIABLE CAPACITOR
Rated (DC) Voltage (URdc) 200V
Size Code 4337
Q @ Freq 1500 @ 1MHz
Adjustment Type Top and Bottom
Capacitance Range 2.5pF~15pF
Adjuster Orientation VERTICAL
Dimensions
Height Seated (Max) 0.402 10.20mm
Length 11mm
Width 9.5mm
Compliance
RoHS Status RoHS Compliant
