GXC15104
RoHS
RoHS compliant
RoHS compliantPackage /
Category Capacitors / Trimmers, Variable Capacitors
Description
FILMTRIM? VARIABLE CAPACITOR Trimmer Capacitor 0.433Lx0.374W 11.00mmx9.50mm 10pF~150pF 100V
PDF
/
Buying Options
Total Price: USD $28.2
Unit Price: USD $28.201092
≥1 USD $28.201092
≥200 USD $11.252866
≥500 USD $10.877377
≥1000 USD $10.690945
Inventory: 6259
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Terminal Shape FLAT
Dielectric Material Polytetrafluoroethylene (PTFE)
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2002
Series FILMTRIM?
Size / Dimension 0.433Lx0.374W 11.00mmx9.50mm
Feature General Purpose
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Voltage - Rated 100V
HTS Code 8532.30.00.90
Terminal Pitch 10mm
Capacitor Type VARIABLE CAPACITOR
Rated (DC) Voltage (URdc) 100V
Size Code 4337
Q @ Freq 1500 @ 1MHz
Adjustment Type Top and Bottom
Capacitance Range 10pF~150pF
Adjuster Orientation VERTICAL
Dimensions
Height Seated (Max) 0.402 10.20mm
Length 11mm
Width 9.5mm
Compliance
RoHS Status RoHS Compliant
