GGP12000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Capacitors / Trimmers, Variable Capacitors
Description
CAP TRIMMER 0.8-12PF 750V
PDF
/
Buying Options
Total Price: USD $27.77
Unit Price: USD $27.7728
≥1 USD $27.7728
≥10 USD $27.21928
Inventory: 82
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type User Defined
Surface Mount NO
Terminal Shape WIRE
Mounting Feature PANEL MOUNT
Dielectric Material Glass
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series PISTONCAP?
Size / Dimension 0.312Dia 7.92mm
Feature General Purpose
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Voltage - Rated 750V
HTS Code 8532.30.00.10
Reference Standard MIL-C-14409B
Capacitor Type VARIABLE CAPACITOR
Rated (DC) Voltage (URdc) 750V
Q @ Freq 500 @ 20MHz
Adjustment Type Top
Capacitance Range 0.8pF~12pF
Multi-turn 1
Dimensions
Height Seated (Max) 0.750 19.05mm
Compliance
RoHS Status RoHS Compliant
